Audiophony CARBON 15A
The Audiophony CARBON15A is a professional 2-way active loudspeaker designed for live performances, DJs, events, fixed installations, and sound reinforcement applications requiring high power and excellent intelligibility. Equipped with a 15-inch woofer and a 1.35-inch polymer diaphragm compression driver, it delivers a powerful, precise, and balanced sound with excellent high-frequency reproduction.
Its 1500W RMS Class D amplifier (1000W for bass and 500W for treble) ensures significant dynamic headroom while maintaining a low weight and quiet operation thanks to its fanless design.
The CARBON15A features an advanced DSP with a 2.4" color display, offering multiple operating modes (Normal, Live, Club, Speech), EQ, delay, HPF filtering, and ducking settings. It can be controlled directly from the speaker or via the CARBONcontrol mobile app, available for iOS and Android.
Thanks to its Bluetooth TWS (True Wireless Stereo) connectivity, it's possible to stream music wirelessly and pair two speakers for stereo sound. Its nitrogen-assisted injection-reinforced cabinet provides increased rigidity and enhanced durability for heavy-duty use.
Key Features
Class D amplification: 1500W RMS / 3000W max
High-power 15" woofer
1.35" polymer diaphragm compression driver
Integrated DSP with 2.4" color display
Remote control via CARBONcontrol app (iOS/Android)
Bluetooth TWS for wireless stereo streaming
2 XLR/Jack combo inputs with automatic Mic/Line switching
Maximum SPL of 131 dB
Reinforced cabinet with nitrogen-assisted injection
Suitable for front-of-house or stage monitor use thanks to its asymmetrical shape
Wood driver: 15" (380 mm)
Voice coil: 2.5"
Compression driver: 1.35" polymer diaphragm
LF amplification: 1000 W RMS Class D
HF amplification: 500 W RMS Class D
Total RMS power: 1500 W
Maximum power: 3000 W
Frequency response: 45 Hz – 20 kHz
Maximum SPL: 131 dB
Dispersion: 90° (H) x 70° (V)
DSP and audio processing
Integrated DSP with 2.4" TFT color display
User presets:
Normal
Live
Club
Speech
Parametric equalizer
High-pass filter (HPF)
Delay control
Ducking function
Position control (Front/Return)
Connectivity
Built-in Bluetooth audio
Bluetooth TWS (True Wireless Stereo)
Remote control via CARBONcontrol app (iOS/Android)
Inputs/Outputs
2 x Combo XLR/6.35 mm Jack inputs
Automatic Mic/Line detection
1 x XLR Link output
Construction
Reinforced polypropylene enclosure with nitrogen-assisted injection
35 mm pole mount
3 M10 rigging points
Vertical or stage monitor use
Protection features
Built-in limiter
Thermal protection
Short-circuit protection
Power supply
220-240 V AC – 50 Hz
Dimensions and weight
Dimensions (W x H x D): 430 x 695 x 395 mm
Weight: 22 kg
